Mini Desktop Wave Selective Soldering Machine High Precision Automated Selective Soldering PCB Assembly Soldering

MOQ: 1 set
Prijs: USD 23800-26800 Per Set
Standard Packaging: Exporteer houten doosverpakking
Delivery Period: 30 werkdagen
Payment Method: T/T, Western Union, MoneyGram
Supply Capacity: 1000 sets/jaar
Gedetailleerde informatie
Product Description
Gedetailleerde informatie
Plaats van herkomst
China
Merknaam
Honeal
Modelnummer
OS-300
Dimensie:
L870mm x W1230mm x H1550mm
Maximale draaggrootte:
Max: 350 (L)*300 (W) (mm)
Bereik:
Max400 ℃
Positie nauwkeurigheid:
+ / - 0,05 mm
De Capaciteit van de soldeerselpot:
13 kg /pc's
Voorverwarmingsmethode:
Boven IR-verwarming
Markeren:

mini desktop selective soldering machine

,

high precision automated soldering machine

,

PCB assembly wave soldering machine

Product Description
Mini Desktop Wave Selective Soldering Machine High Precision Automated Selective Soldering PCB Assembly Soldering
Product Attributes
Attribute Value
Dimension L870mm X W1230mm X H1550mm
Max carrier size Max:350(L)*300(W)(mm)
Temperature setting range Max400 ℃
Position accuracy + / - 0.05 mm
Solder pot capacity 13 kgs /PCS
Preheat method Upper IR heating
Mini Wave Selective Soldering Machine for Electronics Production
Features:
  • The machine integrates flux spraying and soldering
  • The solder pot is fixed, and the PCB board moves to realize soldering
  • Maximum PCB dimensions: 300 x 300mm
  • Small in occupation space and low in energy consumption
  • Manual placement and removal of boards
  • It is particularly suitable for the products of NPI
Technical Parameters
Machine Parameters
Dimensions L870mm X W1230mm X H1550mm
Power supply Single phase 220V 50HZ
Shipping Parameters
Rail adjustable range 50-300MM
PCB board size L350 X W300MM
Transport height 900±30mm
Sports platform Pulley + slide rail
Movement accuracy ±0.25 mm
Tin Furnace Parameters
Crest drive Mechanical pump
Number of tin furnaces Single cylinder
Tin furnace capacity 13 kg / furnace
Nitrogen consumption About 1.5 ~2 m3/h per tin cylinder
Programmatically Manually enter coordinates
Product Details
Mini Desktop Wave Selective Soldering Machine High Precision Automated Selective Soldering PCB Assembly Soldering 0 Mini Desktop Wave Selective Soldering Machine High Precision Automated Selective Soldering PCB Assembly Soldering 1
Certification
Mini Desktop Wave Selective Soldering Machine High Precision Automated Selective Soldering PCB Assembly Soldering 2
Packing
Mini Desktop Wave Selective Soldering Machine High Precision Automated Selective Soldering PCB Assembly Soldering 3
